Quick Details
Type: Air Conditioner Parts, Air Conditioning Fitting
Application: Home
Certification: RoHS
Place of Origin: Zhejiang, China (Mainland)
Brand Name: HUACHUANG
Model Number: 100*58*430MM
color: black
Material: NR/NBR/CR
Size: custom
Temperature: -40 to 230 °C
Hardness: 30-90 shore A
Features: Ductless, Split-System
installation: Wall Bracket
Packaging & Delivery
Packaging Details: | Neutral box, carton, export pallet |
---|
Delivery Detail: | 20~25 days |
---|
| D | H | L | T | W | BC | CS | MBD |
Size | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm |
ND-A | 1-3/16 | 30 | 1-1/2 | 38 | 3-3/16 | 81 | 3/16 | 5 | 1-5/8 | 41 | 2-3/8 | 60 | 5/16-18*3/4" | *19 | 5/16 | 8 |
ND-B | 1-3/4 | 44 | 1-7/8 | 48 | 3-7/8 | 98 | 1/4 | 6 | 2-5/16 | 59 | 3 | 76 | 3/8-16*1" | *25 | 5/16 | 8 |
ND-C | 2-9/16 | 65 | 2-3/4 | 70 | 5-1/2 | 140 | 1/4 | 6 | 3-5/16 | 84 | 4-1/8 | 105 | 1/2-13*1" | *25 | 1/2 | 13 |
ND-D | 3-3/8 | 86 | 2-3/4 | 70 | 6-1/4 | 159 | 5/16 | 8 | 4 | 102 | 5 | 127 | 1/2-13*1" | *25 | 1/2 | 13 |
ND-DS | 3-3/8 | 86 | 2-3/4 | 70 | 6-3/4 | 171 | 5/16 | 8 | 4-3/8 | 111 | 5-1/2 | 140 | 1/2-13*1" | *25 | 1/2 | 13 |
|
| 40 |
| 44 |
| 100 |
| 8 |
| 59 |
|
|
|
|
|
|
WHAT ARE OUR PRODUCTS APPLIED FOR?
For purpose of dust-proof, protection, anti-vibration, anti-slip, sealing, connecting tubing, our rubber products, with/without coated metal parts, are widely used in:
Machinery engineering / chemical / food / construction Industry
Power plants
Automotive
Aviation
Gas & oil
Appliance
Commodity
ARE WE YOUR RIGHT PARTNER?
Customers of Huachuang enjoy one-stop solution since we have been collecting any ideas devoted by frontline staffs to catch the point balancing demand & capacity once founded in 2003.
Materials: Correct rubber compounding, includig NR, SR, NBR, EPDM, IIR IR, Silicon dioxide/Silia gel, etc.Setting right durometer (shore A) according to the finished products. Seeing clearly the shrinking ratio of rubber when compounding and molding at beginning. Anti-ozone treatment. Exterior grade. UV stabilized,acrylic pressure adhesive (PSA) with liner. RoHS or SGS certificate available.
Environment: With certain temperature and humidity, shaping vulcanized rubber.
Metal parts: Making metal parts with own molds in the workshop. With high quality phosphating liquid & adhesive and skilled treatment, gluing the metal parts firmly to the rubber. Reaching requirement like blackening, insulating.
Treatment: Spray paint. Removing the burr, leaving final products with smoothful surface.
Molds: A large range available after collecting years. An independent workshop to make/repair molds with special equipments & experienced technical workers.
Testing & QC: Anti-aging,Tensile strength. Zero tolerance for Crazing,getting tack,hardening,yielding,pulverizing,discoloration,having mildew.
Production management: ISO9001:2000
Friendly to the environment as a responsible organization.
OUR BASIC CUSTOMERS?
In Europe, North America & Japan as well as China.
Customers | Products | Cooperation since | Order QTY |
OTIS | escalator rubber handrail | 2003 | 100,000M/Year |
G H Schallschutz | rubber mats | 2008 | 100,000pcs |
Japan Kawai | Rubber mats | 2005 | 20,000,000pcs/year
|
